010S 28000mm
box stitching machine, box stitching machine spare parts, semi auto stitcher, semi auto stitching machine, Semi Automatic Stitching Machine,Semi Auto Servo Stitching Machine,servo stitching machine, Corrugated Box Joint Stitcher,Corrugated Box Stitching Machine,Carton box joint stitcher,Carton Box Stitching Machine,cardboard box stitching machine
1. Adopt Import Double Servo Control System
2. Applied single, double and irregular corrugated carton stitching
3. Available for single, double and strengthen nail
4. Suitable for 3,5,and 7-Layer carton boxes
5. Operating sizes are adjusted by computer, running errors showed on the screen
6. Automatic counter ejector and bundle sheaves of cartons to make working efficiently
7. Stitching Pitch from 30-120mm adjusted by computer
box stitching machine,two piece joint stitcher,Semi Auto Stitcher,cardboard stitching machine, 1515mmx2800mm
Patent No.:ZL200920130584.9 ZL2009201305285.3

Specification		YXD-010S
		2800mm
Max.Sheet size(A+B)×2		2800mm	110inch
Min.Sheet size(A+B)×2		606mm	23.6inch
Max.Box Length (A)		1050mm	41.3inch
Min. Box Length (A)		123mm	4.9inch
Max. Box Width (B)		600mm	23.6inch
Min. Box Width (B)		150mm	5.9inch
Max. Sheet Height (C+D+C)		1500mm	59inch
Min. Sheet Height (C+D+C)		300mm	11.8inch
Cardboard thickness		3-8mm(3-12mm need customized)
Machine Speed		500 Stitches/Minute
Stitching Pitch		30-120mm
Height of feeder		900mm
The first position of Stitching pitch		25mm
Power Required		4HP
Input Voltage		380V three phase
Stitching wire(width*Thickness)		(0.68-0.75)*(1.8-2.0)mm
Stitching wire tray		2.5kg, big wire feeder 20kg is optional
Machine Length		2800mm
Machine Weight		2000KG
Stitching Type		Single, Double, Tie Stitching: "/ / / /" 、"// // //" 、"// / / / //"
No.of Stitches		1-99 Stitches
Suitable for 3/5-Layer boxes(3mm-8mm),customised size available for 7ply(8-13mm)
Features:
The size can be quickly changed in one minute
Very easy operation no tranning required
Single, double and tie stitching are available, all the nails can be rounded off in one time
Automatic counter ejector, when up to the qty set up on the touch screen, will automatically bundle sheaves of cartons
Adopt double Servo Control system
Stitching pitch can be adjustable to set on the touch screen, amd the max stitching pitch can reach for 120mm
Suitable for boxes with cover or without cover
Rear baffle was Electrically controlled, it has the memory function
Main accessories:
Description		Brand
Stitching head		Taiwan XX
Servo Control System		Japan Yaskawa
PLC		Germany Siemens
Touch Screen		Taiwan Weilun
Machine parts
No	Name	QTY
1	Main machine	1PCS
2	counter ejector	1PCS
3	conveyor roll	1PCS
4	Standing platform	1PCS
